1. Force power saving mode: Hold MODE+A+X and then click START
2. Exit from power saving mode: START or any key on D-PAD
3. 3-buttons controller mode: Hold for 3 sec. MODE+START+C. Required for some games which not compatible with 6-buttons controllers. Golden Axe II, for example
4. SMS controller mode: Hold for 3 sec. MODE+START+B. Required for some SMS games which is not compatible with genesis controllers.
5. Switch controller to normal 6-buttons mode: MODE+START+Z
6. Sync controller with receiver: Hold sync button on receiver for 4 sec until led on receiver will start blinking. Hold MODE+X+Y+Z until led went out.
All compatibility modes (combo 3 and 4) will resets to default after power cycle on receiver
1. Constant led shining: Controller is not connected.
2. Led turned off: Controller connected
3. Slow light pulsation: Low battery level
Package bundle: 1x controller + 1x receiver. Charging cable is not included. Any micro-usb cable can be used for charging
jconfig. Joyzz configuration tool allow to update firmware and change some default controller settings. Windows application, but can be used on mac or linux with mono runtime.
joyzz-inf-sega.bin This little tool is for flashcarts. It show controller system information like signal strength, battery level etc.
